1.1 Electrica Properties
| Parameter |
Description |
| Frequency Band |
5700-5900Mhz |
| Nominal Impedance |
50 ohm |
| Polarization |
Vertical |
| Electrical Wave |
Dipole |
| Return Loss |
Please See Data-1 |
| V.S.W.R |
2.0:1 |
| Antenna Peak Gain |
5dBi |
| Power |
20W |
1.2 Mechanical Properties
| Parameter |
Description |
| Antenna Type |
External Antenna |
| Connector Type |
SMA (M) |
| Antenna Dimensions |
Ø16 x 155mm ±2 |
| Antenna Color |
ASA-UV-Black |
| Operating Temperature Range |
-40°C~+80°C |
| Storage Temperature Range |
-40°C~+80°C |
| Waterproof |
IPX7 |
