FA-38 Car FM Antenna
 |
|
Product Description
100% waterproof IPX8
Product Specifications
|
Physical Condition | |
|---|---|
| Construction | Polycarbonate- radome at top, die-cast shell at bottom/ rubber gasket for water seal in between |
| Dimension | 40.5mm (L) x 38mm (W) x 12.3mm (H) |
| Weight | 50 grams (excluding cable & connector) |
| Standard Mounting | Magnet mount with two magnets & screw mount |
| Optional Mounting Plate | customized metal sheet |
| Environmental Conditions | |
| Operation temperature | -40oC to +85oC |
| Storage temperature | -40oC to +100oC |
| Relative Humidity | 95% non-condensing |
| Cable & Connector | |
| Cable | 5 meter RG174/U (standard) cable, other length available |
| Pulling Strength | 6 Kg @ 5sec with molded plastics on connector end for strain relief |
| Connector Available | BNC,TNC,FME (to be adapted), GT5, MCX (OSX), SMA, SMB or SMC in straight or right angle |
| Optional Adapters | Universal Connector Adapter (FME to TNC/BNC/SMA/SMB/MCX) |
| Antenna Element | |
| Center Frequency | 88~108Mhz |
| Gain | 0dbi |
| VSWR | 4.0:1 |
* This specification is subject to change without prior notice
